A SLIM Chance for Measuring Cell Growth

Facebook X LinkedIn Email
CHAMPAIGN, Ill., Aug. 29, 2011 — A new imaging method that can measure cell mass using two beams of light — called spatial light interference microscopy (SLIM) — offers new insights into whether cells grow at a constant rate or exponentially.

SLIM is extremely sensitive, quantitatively measuring mass with femtogram accuracy. By comparison, a micron-size droplet of water measures 1000 fg. The technique can measure the growth of a single cell, and even mass transport within the cell. Led by Gabriel Popescu, a University of Illinois research team described its work with SLIM in a recent edition of Proceedings of the National Academy of Sciences.

“A significant advantage over existing methods is that we can measure all types of cells — bacteria, mammalian cells, adherent cells, nonadherent cells, single cells and populations” said Mustafa Mir, a co-author of the paper. “And all this while maintaining the sensitivity and the quantitative information that we get.”


Illinois researchers have developed a novel imaging technique, dubbed spatial light interference microscopy, that can quantitatively measure cell mass. (Image: Quantitative Light Imaging Laboratory)

Unlike most other cell-imaging techniques, SLIM — a combination of phase-contrast microscopy and holography — does not need staining or any other special preparation. Because SLIM is completely noninvasive, the researchers can study the natural functions of cells as they occur. The technique uses white light and can be combined with more traditional microscopy techniques, such as fluorescence, to monitor cells as they grow.

Rocky Mountain Instruments - Infrared Optics MR

“We were able to combine more traditional methods with our method because this is just an add-on module to a commercial microscope,” Mir said. “Biologists can use all their old tricks and just add our module on top.”

Because of SLIM’s sensitivity, the researchers could monitor cells’ growth through different phases of the cell cycle. They found that mammalian cells show clear exponential growth during the G2 phase of the cell cycle only, after the DNA replicates and before the cell divides. This information not only has great implications for basic biology, but also for diagnostics, drug development and tissue engineering.

The researchers hope to apply their new knowledge of cell growth to different disease models. For example, they plan to use SLIM to see how growth varies between normal cells and cancer cells, and the effects of treatments on the growth rate.

Popescu is establishing SLIM as a shared resource on the Illinois campus, hoping to harness its flexibility for basic and clinical research in a number of areas.

“It could be used in many applications in both life sciences and materials science,” Popescu said. “The interferometric information can translate to the topography of silicon wafers or semiconductors.”

For more information, visit: www.illinois.edu

Published: August 2011
Glossary
holography
Holography is a technique used to capture and reconstruct three-dimensional images using the principles of interference and diffraction of light. Unlike conventional photography, which records only the intensity of light, holography records both the intensity and phase information of light waves scattered from an object. This allows the faithful reproduction of the object's three-dimensional structure, including its depth, shape, and texture. The process of holography typically involves the...
spatial light interference microscopy
Spatial light interference microscopy (SLIM) is an optical microscopy technique that belongs to the category of quantitative phase imaging methods. It is designed to provide high-resolution, label-free imaging of transparent specimens, such as live cells, by measuring the optical path length variations caused by refractive index differences within the sample. The key principles of spatial light interference microscopy include: Interference microscopy: SLIM utilizes the interference of light...
