Photonics ProductsSpectroscopySpectrometersPortable

Micro-Hyperspec SWIR

  • Company: Headwall Photonics Inc.
  • Type: Portable
  • Measurement Techniques: Reflectance and Transmission
  • Spectral Range (nm): 900 - 2500
  • Max. Resolution (nm): 9.6
  • Pixel Count (total pixels): 384
  • Weight (kg): 2
  • Applications: Defense, Environmental Monitoring, Materials Identification, Scientific Research, Other
  • FWHM Slit Image (nm): 10
  • Spectral Bands: 166
  • Dispersion Per Pixel: 9.6
  • Max. Frame Rate: 450

Focal plane array is MCT; Pixel pitch in microns is 24; Slit length is 10.5mm; Entrance slit width is 25 microns; Aberration-corrected diffraction gratings for wide field of view, high SNR, high spatial and spectral resolution.
Micro-Hyperspec SWIR

Headwall Photonics Inc.
580 Main St.
Bolton, MA 01740
United States
Phone: +1 978-353-4100
Fax: +1 978-348-1864
